Advanced Diagnostics for McLaren Vehicles
SKU: ML001
€1,600.00 (Excl. VAT)
All-new Abrites solution for unlocking various functions and customisations in all McLaren models all by OBD.
The first Abrites license for McLaren vehicles tone for a new range of functionalities for your AVDI! It is the continuation of our work on supercars, presenting you with even more opportunities to develop your business!
All-Abrites solution for McLaren!
All by OBD!
No third-party tools required!
The ML001 allows you to calibrate various modules and align both vehicle and gateway configuration, as well as perform calibrations and adaptations regarding the TCU/PCCU modules. It also includes multiple guided and coding functions.
Functionalities:
- Gateway configuration change
- Align vehicle configuration
- Guided functions
- VIN change
- Transmission Control Unit (TCU) and Performance Control/Chassis Control Unit (PCCU) calibrations and adaptations
For the full list of functionalities, see Technical Specification tab.
Supported vehicles:
- All McLaren models
All McLaren models
Calibration:
- [CCU] Suspenssion Pressure Sensor Calibration
- [SCML/SMCR] Seat Calibration
- [SAS] Zero Position Steering Wheel (Fine Tuning)
- [ESP] Yaw Rate Sensor Calibration
- [SCUG] Steering Column Calibration
- [DMR/DML]Door Windows Calibration
Diagnostic tests:
- [ECM] Cam Control Diagnostics
- [ECM] Catalytic Converted Diagnostics
- [ECM] Purge System Diagnostics
- [ECM] Throttle Adaptations Clear/Save
- [ECM] Secondary Air Diagnostics
Reset:
- [PCCU/TCU] Gear Adaptations Reset
- [PCCU/TCU] Clutch Adaptations Reset
- [TPMS] TPMS Factory Reset
- [ADI/IC] ADI Default Configuration Restore (and Erase)
Configurations:
- [ADI] Radio Configuration
- [BC] Heated Screen Configuration
- [ESP] Dynamometer Mode Enable
VIN change available for:
- ADI
- BC
- CCU
- CRCM
- ECU
- EISB
- EPHS
- ESP
- FMW
- IBS
- IC
- MCU
- ORC
- PCCU
- PTCU
- PDCU
- SBC
- SCML
- SCUG
- TCU
- TPMS
Engine-related guided functions:
- Catalytic Converter Diag
- Purge System Diagnostic
- Secondary Air Diag
- Cam Control Diagnostics
- DMTL Leakage Test
Engine calibration-type guided functions:
- Throttle Adaptation
- Save Throttle Adaptations
- Clear Misfire Calibration
- Brake Bleed → All models supported
- Carbon Ceramic Matrix (CCM) Front/Rear Disc usage Reset → All models above P13 supported
- Electronic Parking Brake (EPB) Assembly Check → All models supported
- Caliper Usage Reset Front/Back → All models above P13 supported
- EPB Maintenance Mode Enter/Exit → All models supported
- Factory Customer Mode Set → P11 supported
- G Sensor Calibration (EPB) → P11 supported
TCU/PCCU calibrations and adaptations:
- [TCU] Air Brake Bleed
- [TCU] Air Brake Calibration
- [TCU] Calibration
- [TCU] Transmission Warmup
- [TCU] Replacement Reset
- [TCU] Synchro Adaptation
- [TCU] Turbo Wastegate Control
- [TCU] Hydraulic Contamination Cleaning
- [TCU] Clutch1/2 Kisspoint Adaptation
- [TCU] Clutch1/2 Preload Adaptation
- [TCU] Clutch1/2 Pressure Current Adaptation
- [TCU] Clutch1/2 Fill Volume Adaptation
- [TCU] Clutch1/2 Fast Fill Volume Adaptation
- [TCU] Line Pressure Adaptation
- [PCCU] Dual Clutch Calibration
- [PCCU] Hydraulic Contamination Cleaning
- [PCCU] Nose lift Maintenance
- [PCCU] Nose Sensor Lift Calibration
- [PCCU] Clear Gear Adaptations
- [PCCU] Damping Sensor Calibration
- McLaren MP4-12C
- McLaren 540C
- McLaren 570S
- McLaren 600LT
- McLaren 650S
- McLaren 625C
- McLaren 620R
- McLaren 675LT
- McLaren 720S
- McLaren 750S
- McLaren 765LT
- McLaren Elva
- McLaren Senna
- McLaren GT
- McLaren Speedtail
- McLaren P1
- And all variations of the models listed above (Spyder, GTR, etc.)
