TN00F - Full ABRITES Software Package for Toyota and Lexus vehicles

This package contains the TN014, TN015, TN016, TN017, TN019 special functions.

Thе TN014 license expands the key programming capabilities of the ABRITES software for the latest generations Toyota vehicles, equipped with Tokai Rika Smart System with BA type HT-AES keys.

Functionalities:

• Spare key programming
• ALL KEYS LOST

Supported models:

• Yaris 2020+ (XP210)
• Yaris Cross 2021+ (XP210)
• Corolla Facelift 2022+ (E210)
• Corolla Cross Facelift 2022+ (XG10)

Including the models, already supported in the TN011 legacy license:

• Corolla 2018+
• Camry 2018+
• Highlander 2018+
• Mirai 2020+

No additional subscriptions (dealer access) are required to complete the key programming procedure.

This solution covers said models, regardless of the market on which they are offered - all versions of the models are supported (US, European, UK, Asia). Smart system reset is NOT needed, nor a connection to Toyota servers.

Depending on the transponder type in the vehicle, either a HT-AES (TA64) or a DST-AES (TA68) emulator will be required. CB012 will also be required for internal CAN-BUS connection to the vehicle.
An AVDI interface with a valid AMS subscription, a ZN002 or ZN003 PROTAG V2 Programmer are required to use this license.

The TN015 is a step further in the development of key programming solutions for Toyota vehicles by ABRITES. Our team has created a license for a selection of vehicles, manufactured after 2020, equipped with a Denso Smart System with BA type DST-AES keys.

Functionalities:

• Spare key programming
• ALL KEYS LOST

Supported models:
Sienna 2020+ (XL40)
Harrier/Venza 2020+ (XU80)
Tundra 2021+ (XK70)
Land Cruiser 2021+ (J300)
RAV4 Facelift 2022+ (XA50)

Including the models, already supported by the TN012 legacy license:

• CH-R 2018+
• Prius 2018+
• Avalon 2018+
• RAV4 2018+

No additional subscriptions (dealer access) are required to complete the key programming procedure.

In order to perform the procedure, the TA68 DST-AES emulator is needed. CB012 will also be required for internal CAN-BUS connection to the vehicle.
An AVDI interface with a valid AMS subscription, a ZN002 or ZN003 PROTAG V2 Programmer are required to use this license.


The TN016 license provides a complete key programming software solution for the full range of Lexus vehicles, produced after 2018.
Even the latest 2022 RX and NX models with B9 DST-AES keys and Denso Smart System are supported.

Functionalities:

• ALL KEYS LOST key programming
• Spare key programming completely by OBDII

Supported models:

• RX 2022+
• NX 2021+
• RXL 2018+
• ES 2018+
• LS 2018+
• UX 2018+

Stable Internet connection and the ZN002 or ZN003 PROTAG Programmer, as well as the TA68 DST-AES transponder emulator and the CB012 cable set are needed to complete the procedures.

The TN017 license allows you to reset and adapt the ID-code box unit of all Toyota and Lexus models, produced until 2024.
The reset of the ID Code Box opens up many possibilities for those working on Toyota/Lexus vehicles, mainly due to its location and the long time it takes for the vehicle to be dismantled until the ID Code Box is removed.

Functionality:

• ID-Code-Box reset (via LIN-BUS)
• ID-Code-Box adaptation in vehicle (new or reset second-hand module) to the Smart System via OBD
• ID-Code-Box adaptation in vehicle (new or reset second-hand module) to the Engine Control Unit via OBD

When ID-Code Box replacement is needed, this license allows you to reset a second hand module and adapt it as a replacement, as well as adapt a brand new one to the vehicle easily.
The procedure for resetting the ID-code box is required when the ID code box itself, smart system and/or Engine Control Unit (ECU) need to be replaced. Replacing the smart system requires pairing it with the ID-code box. In order to pair the ID-code box to the smart system, resetting the ID-Code box is obligatory. The same procedure applies to the Engine Control Unit.
Smart System and Engine Control Unit do not require taking out the ID code box in case of exchange.
ID Code box reset is made easier and quicker regardless of the presence of an ESL module in the car!
When a virgin ID-code box is installed in the vehicle, synchronisation with the ECU and Smart system is required, as well as a working key. The TN017 allows you to perform this synchronisation via OBDII.

Supported vehicles:

• All Toyota and Lexus models up to 2024

In order to perform ID-Code-Box reset procedure, internal CAN-BUS and internal LIN-BUS connections are needed, use the CB012 and CB031 cables for this purpose. The legacy TN009 license is required in order to use the full ID-Code-Box reset functionality and it is included in this software license.
In case the ID-Code-Box reset function is not possible for the module you are working with, please contact us at support@abrites.com and send us the module to add in the supported list.

The TN019 license allows you to perform calibration of mileage in dashboards with S6J3 microcontrollers, installed in Toyota and Lexus vehicles. The procedure is done in a few minutes via OBDII or internal CAN Bus connection.

Functionality:

• Calibration of dashboards using S6J3 microcontrollers


Supported vehicles:
ALL Toyota and Lexus vehicles whose dashboards are equipped with S6J3 microcontrollers, such as:

• Toyota Camry 2018+
• Toyota Corolla 2019+
• Toyota RAV4 2019+
• Toyota Yaris 2018+
• Lexus LS

Older models (those with AA/A9 keys) are supported by OBDII while for newer (BA/B9 keys) internal CAN-Bus connection is required. The CB012 and CB031 cables are needed to establish a connection to the module and complete the procedure successfully for certain models.
Please, refer to the Abrites Diagnostics for Toyota/Lexus/Scion User Manual for additional information on the procedures.
AVDI with an active AMS is needed to purchase and use this package.
