Abrites Vehicle Diagnostic Interface (AVDI)

What is the Abrites Vehicle Diagnostic Interface (AVDI) The state of the art AVDI covers a range of functionality that is often not available even with OEM tools. Basic diagnostic functionality such as module identification, reading/clearing Diagnostic Trouble Codes (DTCs), live data display and actuator testing is covered in the basic package with a lot of special functions such as module virginisation and adaptation, key programming and module recalibration also included (subject to purchasing the relevant additional software).

The basic diagnostic package is the gateway to the world of diagnostics and is designed so that the customer can perform many jobs with a minimal investment.

Abrites Vehicle Diagnostic Interface (AVDI)

DIAGNOSTICS

KEY PROGRAMMING

MODULE ADAPTATION

WHAT'S INSIDE THE PACKAGE?

TECHNICAL SPECIFICATIONS

K-line ISO 9141 (100 mA) multiplexed to 24 different pins of the diagnostic connector

ISO14230 compliant

SAE J1850 VPW,
PWM compliant (additional adapter required)

Single wire CAN bus multiplexed to different pins of diagnostic connector

Dual wire low speed CAN bus multiplexed to different pins of diagnostic connector

Dual wire high speed CAN bus multiplexed to different pins of diagnostic connector

CAN bus GMLAN,  ISO14229,
ISO15765, J1939, ISO22901 compliant

Analog Input USB interface to the PC Supply voltage 8..30V DC OBDII cable

Updatable firmware

Supported brands
