Additional Hardware Kit for Subaru Vehicles by ABRITES

The ABRITES Additional Hardware Kit for Subaru Vehicles contains two proprietary emulators and a jumper cable for Subaru vehicles:

•    DST-AES Transponder Emulator for Toyota and Subaru vehicles (TA68)
•    DST-AES Emulator for Subaru vehicles (TA41)
•    Jumper Cable (CB021)

These additional tools complement the work of AVDI, ZN003 PROTAG and ZN085 H850/V850 Programmer, available in the Starter Pack Plus HERE.
The Complete ABRITES Software Pack for Subaru vehicles offer you all the ABRITES software licenses for the brand HERE.

The TA68 is a reusable transponder emulator designed to emulate ALL DST-AES transponders where Page 1 is 88, A8 and A9. The TA68 covers the full functionality of its predecessor, the TA30, and expands the list of supported vehicles. The TA68 is placed in our signature shell, giving the product a sleek finish.

Main functionalities:
•    ALL DST-AES transponder programming (where Page 1 is 88, A8 and A9)
•    Writing and locking all pages of the EEPROM
•    Writing and locking ALL KEYS
•    TIRIS AES verifying of a AES1 crypto key

Supported vehicles (using DST-AES transponders ):
•    Toyota models
•    Subaru models
•    and all other brands using them

You will require the PROTAG and the TagKeyTool (included in the PROTAG package) in order to use this product.
Depending on the brand of the vehicle, you will also need the corresponding Toyota (TN014 or TN015) or Subaru (SB002) special functions.
When performing the procedures, please refer to the Abrites User Manual for the respective brand.

The TA41 Subaru DST-AES Emulator is used to either emulate a Master key, or be used as a key for Subaru H-type bladed keys. It requires the PROTAG Programmer to be programmed.
It is used together with the ABRITES Diagnostics for Subaru vehicles both ALL KEYS LOST H-type bladed (mechanical) key situations as an emulator and spare key programming as the spare key.
The TA41 can be used as a substitute for the ZN066, but will require a PROTAG to do so.

The CB021 jumper cable is used for internal CAN connection when performing key learning procedures. It is also applicable for mileage recalibration and module replacement in a selection of models.
