Kia/Hyundai

ABRITES Diagnostics for Kia and Hyundai is an advanced diagnostic software designed to work with the Abrites Vehicle Diagnostic Interface that allows the user to perform standard and advanced dealer level diagnostics on Kia and Hyundai vehicles.



GENERAL DIAGNOSTICS

Standard diagnostic functions include live data display, module identification, reading and clearing of diagnostic trouble codes (DTCs) on a dealer level. Display of DTCs in the following languages:
English, French, Spanish, German, Italian, Russian, Czech, Polish, Bulgairan, Chinese, Turkish, Greek, Hungarian. Actuator tests - Fan speed actuation, lamps activation and so on.

The Advanced diagnostics functions include key-learning, module and mileage calibration.

The key learning function works only by K-Line and CAN. The Hyundai/KIA Immobiliser system consists of the SMARTRA ECU which has its own CPU which controls the vehicle's immobiliser in conjunction with the engine management ECU. The key learning function in general works for all Hyundai/KIA vehicles manufactured since 2000. Please, see a list of the supported vehicles on which the key learning function is guranteed to work below. In the next versions we will add more vehicles to this list FREE for all customers who own the key learning function.

SPECIAL FUNCTIONS

NEW FEATURES FOR ADAPTATION:

For vehicles with a smart key:

  • neutralisation (allowing adaptation in other vehicles) of the smart system

  • neutralisation (allowing adaptation in other vehicles) of the ECU

  • neutralisation (allowing adaptation in other vehicles) of the ESCL

  • neutralisation (allowing adaptation in other vehicles) of the PDM (for vehicles equipped with PDM)

For vehicles with a mechanical key:

  • neutralisation (allowing adaptation in other vehicles) of the immobiliser - this automatically neutralises the ECU as well

  • neutralisation (allowing adaptation in other vehicles) of the Smartra module (for vehicles that are equipped with one)

Live data demonstrating the state of the modules (neutralised/active) and the number of initialised keys is shown in the function window for comfort.

Please note that the keys have to be relearned to the vehicle after installing a neutralised module.

PIN and Key Manager

All your key programming and PIN code reading needs in one software

PIN CODE READING and KEY PROGRAMMING for almost 100% of ALL the models. 2018 models included!

- DENSO SMART SYSTEMS PIN CODE READING NOW AVAILABLE!!!

- PIN code reading and key programming for vehicles with Smart Keys

- PIN code reading and key programming for vehicles with mechanical key and Delphi DCM3.7 ECUs

- PIN code reading from working mechanical keys. DST80 type. This functionality requires ZN002 PROTAG.

The current support list also includes pin code reading and key programming for all vehicles with mechanical key and an ECU from the following brands: Delphi, Kefico, Bosch EDC15/ EDC16

Included in the new HK008 special function.

We now support cloning of DST 80 transponders for:

- HYUNDAI/ KIA you need PROTAG for this features.



Key Programming by CAN and K-Line for the following models by OBDII. The list may include other vehicles. Almost 100% of the models are now supported:



KIA Morning

KIA Sephia

KIA Sportage

KIA New Morning

KIA Optima

KIA Sorento

KIA Euro Start

KIA Magentis

KIA Mohave

KIA Naza Suria

KIA Rio

KIA Borrego

KIA Naza Picanto

KIA Venga

KIA Rondo

KIA Ceed

KIA Forte

KIA Carnival

KIA Cerato

KIA Opirus

KIA Sedona

KIA Carens

KIA Amanti

KIA Visto

KIA Soul

KIA Cadenza

KIA Sportage

KIA Picanto

KIA Sportage

KIA Spectra

Hyundai Avante

Hyundai H200

Hyundai Tucson

Hyundai Sonata

Hyundai SantaFe

Hyundai Getz

Hyundai Grandeur

Hyundai Veracruz

Hyundai Atos

Hyundai H100

Hyundai Terracan

Dodge Atos

Dodge Attitude

Hyundai Santo Xing

Hyundai i30

Hyundai Genesis

Hyundai Porter

Hyundai Entourage

Hyundai Equus

Hyundai Libero

Hyundai Coupe

Hyundai i20

Hyundai i10

Hyundai i800

Hyundai Accent

Hyundai Verna

Hyundai Elantra

- PIN by VIN calculator for vehicles up to year 09.2007
- Automatic Pin Code reading in vehicles equipped with KEFICO Engine Control Units (petrol engines) with processor ST10F275, EDC15C2, EDC1639
- Read/Write Flash and automatic flash checksum calculation of EDC16 Engine Control Units (which is also the Immobilizer control unit). Automatic Pin Code reading for EDC16

Instrument Cluster, Engine Control Data Manager

Cluster calibration and Read/update ConfData of instrument cluster for the following models by OBDII:

KIA Ceed 2011 - 2013 KIA Optima 2010 - 2013 KIA Magentis 2010 - 2013
KIA Rio 2011 - 2013 KIA Soul 2011 - 2013 KIA Sportage 2011 - 2013
KIA Sorento 2011 - 2013 Hyundai Elantra 2011 - 2013 Hyundai I20 2011 - 2013
Hyundai Solaris 2011 - 2013 SaangYong Korando 2011 - 2013

- Calibration by OBD in Engine Control Units EDC15
- Read/update ConfData and Flash of EDC15 Engine Control Units (which is also the Immobilizer control unit). Pin Code extraction by OBD

Engine Control Unit Flash Manager

Reading and updating ECU’s flash and configuration memory by diagnostic. ECU EDC15/16.



Screenshots:



Hyundai main Hyundai special
