BMW/MINI

Established as the world leader the Abrites diagnostics for BMW often surpassed other aftermarket and even the OEM tools in Diagnostics, Module replacement, Key programming, Coding and Programming. Completely online with a great, easy to use interface.

DIAGNOSTICS

The following applies to the BMW/ Mini E, F and G series vehicles including Rolls Royce models.

  • Reading Diagnostic Trouble Codes (DTC).

  • Clearing Diagnostic Trouble Codes (DTC).

  • Full guide through the DTC with possible scenarios and complete descriptions.

  • Monitoring Live Values from all electronic modules installed in BMW and Mini vehicles.

  • Live data monitoring from multiple modules at the same time with multiple actuator activation.

  • Actuator testing for thousands of actuators from all electronic modules.

  • Simultaneous operation of actuator tests while monitoring live data.

  • Recording values of the vehicle while performing testing for analysis.

  • Guided functions.

  • Graph and table displays.

  • Outstanding graphic user interface.

CODING/ PROGRAMMING

All Coding/ flashing/ Programming can be performed in accordance to the vehicle’s Integration Level (I-LEVEL). You can also choose to disregard it. -Default coding writing to electronic modules.  Allows you to set the coding without the need of a coding file. We generate our own coding files.



  • Coding files are saved in a format accessible to most tools for BMW, such as ISTA P and E-SYS.

  • Full coding ability for E and F series vehicles allowing retrofits of options such as cameras, seat heating, modifications and thousands of others.

  • Vehicle personalization according to each customer’s specifications and requirements. Speed limiter removals, video in motion

  • Vehicle order (VO) reading, saving, modifications and writing.

  • Retrofits

  •

  • FAST CODING options. Hundreds of fast coding options which can be turned on or off with a single click:

  • Replacement of the DME/ DDE module for E and F series (With or without CAS module encryption)

  • Replacement of the ZF6HP (not applicable for F series vehicles) and ZF8HP EGS gearbox modules for E and F series (for 8HP in E series you need the donor car’s DME/ DDE or dump from it while for F series you do not need it).

  • Replacement of FEM/ BDC modules in F series completely while retaining the original coding of the vehicle.

  • Making FEM/ BDC modules virgin in order for them to be replaced.

  • FEM mileage reset for seamless adaptation. Reset shadow memory.

  • Change ID (VIN) available for many modules including FEM and DME/ DDE.

  • Replacement of secondary electronic modules (not directly related to the vehicle’s operation) such as:

    • FRM

    • A/C

    • Others

  • Xdrive all wheel drive module replacement of the transfer case.

    • FSC coding for navigational system updates for CCC/ CIC/ NBT navigation systems.

KEY PROGRAMMING

  • CAS4, CAS4+ Completely by OBD even if all keys are lost
  • Key and remote programming for Car Access System (CAS)/ FEM/ BDC types of cars (performed for Keyless and non- Keyless keys, new or used).
  • Individual Serial Number (ISN) reading from the DME/ DDE modules and CAS1/ 2/ 3/ 3+ (reading/ and encryption is also available for CAS modules).
  • Boot mode reading of DME/ DDE with comprehensive wiring diagrams.
  • Boot mode ISN visualization
  • Reset working hours via boot mode.
  • CAS- ELV; CAS- DME synchronizations.
  • CAS1/ CAS2/ CAS3/ CAS3+ completely by OBD for adding a key or programming all keys lost. Reflashing the CAS3+ module might be required but thanks to our flash database this is an easy task.
  • CAS4 cars by dump from the CAS module or completely by OBD for F series.
  • FEM/ BDC key programming for additional keys and all keys lost (F series). Up to 2018.
  • We can use:
    • Original NEW E and F series keys
    • Original E and F series keys (they can easily be renewed using the ABPROG software and programming).
  • Aftermarket keys of good quality.
  • BMW Bikes key programming for DST 80 and Hitag 2 models up to EWS4 by dump.

ISN matrix compatibility



Series series
1
series 2 series
3
series 4 series
5
series 6 series 7 models
X
models Z models M models Mini
  E81/E87 E82/E88 F20/F21 F22 E46 E90 F30 F32 E39 E60/E61 F10 F10 E63/E64 F06 E65 X1 X3-E83 X3 X3 X5-E53 X5-E70 X6-E71 Z4-E85 Z3 X5M/X6M M3/M5/M6 R56
Year 2004-2011 2007-2013 2011+ 2013 2000-2004 2005-2011 2012+ 2013+ 2001-2003 2003-2009 2011+ 2013+ 2004-2009 2012+ 2002-2007 2010+ 2003-2010 2011+ 2013+ 2000-2006 2007-2013 2008+ 2002-2006 2001-2002 2010-2013 2010-2011 2006-2013
ME9
EDC16 320d
330d
335d
520d
530d
535d
3.0d 3.0d 3.0d
3.5d
3.0d
3.5d
1.6d
EDC17 3.0d
3.5d
4.0d
3.0d
3.5d
4.0d
MSV70 130i 323i
325i
325xi
330i
330xi
525i 2.5si
3.0si
MEV9N46L 318i
MEVD17 3.5i 3.5i
MEVD172Y 135i 228i 320i
328i
328ix
428i
428ix
528i
528ix
2.8i 2.8i
MEVD172 535i 640i 3.5i
MEVD1724 328i 535i
MEVD1725 535i
MS43 320i 520i 520i
(2003
-
2005)
2.2i 2.2i
N62_TUE/2 550i 650i
ME9N62
MSV80
MSV80.1
128i
135i
325i
325xi
328i
328xi
335i
335xi
525i
528i
530i
3.0i 2.3i
2.8i
5.0i
MSD80
MSD80.2
318i
335i
MSD81 323i
325i
535i
535xi
535i 3.5i 3.5i 2.5si
3.0si
MSD81.2 320i
MSD85 5.0i 5.0i
MSS60
MEV172
MED172
MEV1722



BMW MOTORCYCLES (BMW MOTORRAD):

 Complete OEM and higher level of diagnostics:

- Reading and clearing DTCs with the ability to show causes and possible fixes.

- Full DTC details with descriptions.

- Actuator testing and activation.

- Live values in table or graph mode.

- Simultaneous use of Actuators and live value monitoring

- Key programming for BMW Motorcycles and scooters using HITAG 2, DST 80 and DST AES keys for example: S1000RR; BMW K19 - C600 and C650; BMW GS1200/ GS1200R; K and F series (K1300 and F800) commonly known as XEWS4 type. They use DST80 transponders so you can use the Abrites TA36 as a key.BMW R1200GS using a handsfree unit (Keyless go system) X_SLZ/ HUF. These use a DST AES type of key and others.

- Module replacement for  BMW Motorcycles and scooters.

  • EWS replacement.

  • ABS replacement.

  • Cluster replacement.

  • DME replacement.

- Coding and Programming for BMW Motorcycles and scooters.

  • Vehicle order (VO).

  • Programming of flashes in the modules.

  • Integration level.

  • Customisation for various modules according to the customer's requests.



ADDITIONAL FEATURES

Online based software allowing continuous integration of updates directly with the help of an automated update process.
J2534 Passthru Support for ISTA- D, NCS Expert, Tool 32
