Silencing the Storm: Master JLR Alarm OFF Functionality with Abrites

When dealing with Jaguar and Land Rover (JLR) vehicles, particularly in All Keys Lost (AKL) situations, the first and often loudest obstacle is the factory alarm.
For years, the security infrastructure of JLR vehicles has evolved from simple immobilizers to the sophisticated, high-security BCM (Body Control Module) systems we see today.

To keep up with these advancements, Abrites has consistently revised its diagnostic ecosystem. Whether you are using our established offline tools or the cutting-edge online software, our mission remains the same: providing the "Impossible" solutions.
Today, we’re diving into a crucial update for every JLR specialist: the Alarm OFF functionality.

I. A Brief History of JLR Security

JLR security has undergone massive shifts. In the early 2010s, key programming was relatively straightforward. However, starting around 2014, the introduction of locked BCM modules (HPLA, JPLA, and later K8D2/LLPA) changed the game. These modules were designed to prevent unauthorized access via the OBDII port, especially when the alarm is active. Without a working key to disarm the system, the vehicle remains in a "locked" state, frequently blocking communication with standard diagnostic tools.

II. The Solution: JL007 License

The newly revised Abrites diagnostics for JLR (both Online and Offline) now features a robust solution for these scenarios. The JL007 license is specifically developed for models from 2014 to 2024 that utilize locked BCM modules.
The primary goal of JL007 is simple but vital: Disable the alarm of vehicles with a locked BCM to allow for further diagnostic and programming procedures.

Supported Modules and Models: The JL007 license covers an extensive range of vehicles equipped with specific BCM types:

• HPLA Modules (2014–2018): Range Rover (L405), RR Sport (L494), Discovery 4, Discovery Sport, Evoque (L538), Jaguar XF, XE, F-Type, and XJ.

• JPLA Modules (2017–2020): Discovery (L462), Velar, RR Sport/RR Facelifts, Evoque (L551), Discovery Sport, Jaguar F-PACE, E-PACE, and I-PACE.

• LLPA, or M8D2Modules (2020–2022): Evoque (L551), Discovery Sport, Jaguar E-PACE, and F-PACE Facelift.

• K8D2 & L8B2 Modules (2020–2024): The latest generations including the Land Rover Defender (L663), Range Rover Sport (L461), and Velar.


Hardware and Software Requirements: To execute the Alarm OFF procedure, you need a specific toolkit to ensure a stable and successful connection:

1. AVDI: The foundation of all Abrites diagnostics.
2. Active AMS: Ensure your Annual Maintenance Subscription is current to access the latest online/offline software updates.
3. JL007 License: The specific software authorization for Alarm OFF functionality.
4. CB012 Cable Set: This is the Direct CAN-BUS/LIN-BUS Connection Cable Set. Because the alarm blocks OBDII communication, you must connect directly to the vehicle's internal communication bus.


III. Technical Insight: How to Connect

According to Section 13.6 of the Abrites Diagnostics for JLR User Manual, the process involves connecting the CB012 cable set directly to the BCM or the gateway of the vehicle.
By establishing a direct link to the CAN-BUS, the AVDI can bypass the restrictions of the locked OBDII port. Once the "Alarm OFF" command is executed via the software, the vehicle’s security system is neutralized, allowing you to proceed with key programming or other maintenance tasks without the siren or immobilization interfering.(Note: Please refer to page 46 of the user manual for the detailed connection diagrams and pinouts specific to your module type.)

Understanding the Gatekeepers: KVM vs. BCM

To master JLR security, one must distinguish between the KVM (Keyless Vehicle Module) and the BCM (Body Control Module). In older generations (pre-2014), the KVM was the primary target for key programming, as it handled the wireless handshake with the key fob. However, in the newer 2014–2024 architecture covered by the JL007 license, the BCM has taken on a more dominant role. While the KVM still manages the "handshake," the BCM acts as the master security gateway. If the BCM is armed and the alarm is active, it effectively shuts down the communication lines (CAN-BUS) to the rest of the vehicle. This is why the Alarm OFF functionality focuses on the BCM—you must "wake up" the BCM before you can even begin talking to the KVM for key programming.

IV. Conclusion

The evolution of JLR security requires a professional response. With the JL007 license and the CB012 cable set, Abrites users can confidently tackle All Keys Lost situations on the latest 2024 models.
Stay ahead of the curve by ensuring your software is updated and your hardware is ready for the next challenge.

P.S. Unofficial table, not proven!

1. First generation (pre-2010 → ~2012)
    AH22
    BH22
    9X23

2. Second generation (~2010 → 2016)

   BJ32 (VERY common)
   DPLA
   CPLA

3.New generation BCM (~2017 → present)

  HPLA
  JPLA
  K8D2
   L8D2 / M8D2 (newer)
   S8E2


For more technical details, visit our JLR User Manual or contact our support team. Achieve the impossible with Abrites!
