Additional Hardware Kit for Mercedes-Benz Passenger Vehicles by ABRITES

This powerful set allows you to work with various modules in Mercedes-Benz cars: ECU, TCU, ELV, DSM/ISM for the following procedures:
•    Working with FBS4 modules: Set to virgin state, Adaptation, Programming, Activation
•    Dashboard calibration
•    ELV/ESL repair
•    VGS4-NAG2 transmission control unit replacement

Keep in mind, that you will require the Complete ABRITES Software Pack for Mercedes-Benz Cars to complete all these procedures, as well as the essential hardware, you can find in the Starter Pack and the Starter Pack Plus. We recommend the Starter Plus in order to get ALL the leading tools by ABRITES.

The ABRITES Additional Hardware Kit for Mercedes-Benz passenger vehicles contains all the equipment (besides the essential AVDI and programmers) for working with these vehicles.
•    Mercedes-Benz MD1/MG1 ECU connection cable for FBS4 Manager and ECU Programming Tool (CB030)
•    EZS Bench Connection Cable for Mercedes (CB033)
•    DSM/ISM Direct CAN BUS Connection Cable (CB034)
•    7G-Tronic VGS4-0 NAG2 FBS4 Solder-Free Connection Set (SET088)
•    Direct CAN-BUS/LIN-BUS Connection Cable Set (CB012)
•    FBS4/FBS3 ELV Connection Cable (CB026)
•    ECU Reading Set (ZN074)
•    USB IR Adapter (ZN076)
•    Adapter for ZN085 - 5V to 3.3V (ZN092)
•    Universal BGA Mercedes-Benz key (433/315 MHz) (TA52)
•    Emulator for IC223/IC177 M Dashboards in Mercedes-Benz vehicles (EM019)

The CB030 cable is intended for direct connection on bench with the engine control units from BOSCH types MD1, MG1 in Mercedes-Benz vehicles and vans.
The cable is useful for diagnostic purposes on bench, and of course for FLASH/DFLASH programming.
The CB033 cable is designed and developed for use with AVDI on bench, to work with EZS modules from Mercedes-Benz vehicles.
Functionality:
•    Bench work with EZS/EIS modules from Mercedes-Benz vehicles
The CB034 cable is equipped with connectors for EZS/EIS modules, connector for IC (instrument cluster), connector for GATEWAY (W211) and an OBD connector for CB100/CB106 cable for AVDI and ZN151 Distribution Box Set (or the old version of the DS box ZN051), and a DC connector for 12V power supply adapter.
In case of EZS/ELV password extraction, the EZS/EIS fuse is used, to reset the module via the ZN151 DS Box Set or ZN051 DS Box.
Supported modules:
EZS (EIS) - electronic starter switch in the following models:
•    W117/W156/W166
•    W164
•    W207
•    W204
•    W212
•    W221
The SET088 contains all the necessary hardware tools to open and connect to the 7G-Tronic VGS4-0 NAG2 in FBS4 vehicles of the Mercedes-Benz car range. This connection set allows you to easily open the transmission control unit and connect to the required points without soldering.
SET088 guarantees effortless and quick work with the 7G-Tronic VGS4-0 NAG2 TCUs, so that you can read the data stored in them, reset and adapt the modules. In order to complete these procedures, the MN035 license (VGS4-NAG2 FBS4 Virgin/Personalization via ABPROG) is required. This software license enables you to set the TCUs to virgin state, and personalize them in a few easy steps.
The set in combination with the MN035 license offers a great way to reuse second-hand modules in FBS4 vehicles, enabling you to reset the donor module, and adapt it into the vehicle.
Functionalities:
•    Effortlessly open the transmission control unit type 7G-Tronic VGS4-0 NAG2
Connect to the correct points on the module’s PCB using a custom designated adapter

Supported vehicles:
•    All vehicles with VGS4-0 NAG2 7G-Tronic TCU of the FBS4/DAS4 generation Mercedes-Benz

Contents of the set:
•    ZN088 - 7G-Tronic VGS4-0 NAG2 FBS4 Solder-Free Connection Adapter
•    CB088 - 7G-Tronic VGS2/3/4-0 NAG2 FBS3/FBS4 Direct CAN BUS Connection Cable
•    ZN045 – Adapter
•    ZN090 - JTAG Adapter
•    MT001 – Custom drill head
•    CB101 - AVDI extension cable
This CB012 cable set for direct CAN-BUS connection is a proprietary hardware, designed, developed and produced by ABRITES. It is a universal solution when direct connection to the CAN-BUS or LIN-BUS network is required. The CB012 needs to be connected between the AVDI and the OBDII cable.
The CB026 ELV Connection cable is developed to establish a connection between AVDI and FBS3/FBS4 Mercedes-Benz vehicles equipped with an ELV.
The ZN074 set is developed and designed by the Abrites Team to aid you in ECU reading and writing procedures on bench. It is designed to work together with ZN051 Distribution Box and cannot be used individually. The ZN074 works great with the Abrites Engine Control Unit Programming tool and EP00X licenses.
Contents:
•    14V/4A DC Power adapter - used as a charger for ECU, DSBox and AVDI on bench. (EU Plug 110-220V)
•    Connecting cable Power Supply -> DSBox (banana plug)
•    Boot Test Probe - used for easier connection to the ECU’s Boot pin
•    2-footer probe positioner - used for holding the Boot test probe in place, so that your hands are free
•    Micro-Pincer Hook (opening 0.76mm) - used for BGA ball hook up, when the Boot pin of the ECU PCB is not accessible
•    Boot probe connection cable (2mm banana plug, len 0,5m) - used for connecting the Boot test probe or the Micro-pincer hook to the DSBox
•    2mm banana socket - used for soldering to the Boot cable, coming from the DSBox, in order to connect the Boot probe connection cable.

It can also be used as a power supply for:
•    ZN059 - VAG VDO Cluster Adapter
•    ZN060 - VAG Micronas (new style connector) Cluster Adapter
•    ZN061 - VAG Micronas (old-style connector) Cluster Adapter
•    ZN069 - Toyota mechanical key (H-type) adapter set
•    ZN079 - ZF 8HP TCU Connection Cable
•    ZN055 - ABPROG EWS3 adapter
The ZN076 infrared adapter set is designed to be used for reading information from the EZS/EIS of Mercedes-Benz vehicles with IR locks. This information is required when performing key programming and module replacement procedures on these vehicles.
Functionalities:
•    Reading the EZS/EIS of Mercedes-Benz vehicles with Infrared locks
•    IR key emulation
Using this set you can establish a direct connection between the EZS/EIS module and your laptop via an IR key at one end, and a USB plug at the other.
The ZN092 adapter is used together with the ZN085 ABRITES RH850/V850 Programmer for working with automotive modules on bench. It shifts 5-volt logic level of the programmer to 3.3 volts.
Functionality:
•    Shifts the 5 volt logic level of the ZN085 programmer to 3.3 volts.
Supported modules:
•    For MCU’s using the 3v3 logic levels
•    Non-brand specific
The TA52 universal BGA Mercedes-Benz key is designed to be programmed to Mercedes-Benz FBS3 vehicles. The key is programmed completely by OBDII and allows for the frequency to be changed from 433 MHz to 315 MHz (and vice versa) using the PROTAG Programmer. The key is shipped in a replica shell with a blank key blade.
The EM019 emulator for IC223/IC177 M Dashboards in Mercedes-Benz vehicles is used in dashboard calibration procedures and is left inside the module after software work is done.
