The Abrites diagnostics for Renault/ Dacia/ Samsung (Online/ Cloud Software)

In typical Abrites style the Abrites diagnostics for Renault/ Dacia/ Samsung (Online/ Cloud Software) allows its users to cover OEM levels of diagnostics at a fraction of the costs of the original equipment. As with many of our other tools we have a vast array of Module identification, Diagnostic Trouble Code (DTC) reading capability allowing you to scan CAN, UDS based cars with a single button, the software has an intelligent search engine which autodetects the vehicle type and selects the make and model of the vehicle automatically upon scanning for DTCs. You will then have the full information the car has about each of its errors so that it can easily allow you to determine the cause of any fault within the range of the vehicle OBDII diagnostics. The Abrites diagnostics for Renault/ Dacia/ Samsung (Online/ Cloud Software) also provides live value viewing from all electronic control modules simultaneously from multiple sources meaning that you can monitor data from many modules and inputs at the same time in both a graph and table form in order to correctly determine the cause of any fault. Actuator testing is also one of the features available using the basic Abrites diagnostics for Renault/ Dacia/ Samsung (Online/ Cloud Software). VIN ID is also available as an additional feature to replace and renew electronic modules with used modules from other cars. Electric Power Steering (EPS), UCH module, ESL, Airbag and many others can also  be renewed to provide a unique option to adapt used modules to the vehicles. Covered vehicles include ALL CAN and UDS based vehicles from Renault, Dacia and Samsung as well as most K-line based models, however the focus of the software always falls on the newest possible models.

Here are some of the key features you should expect when you get the AVDI and the Abrites diagnostics for Renault/ Dacia/ Samsung (Online/ Cloud Software):

Identifying all the modules available in a vehicle is something very important while prforming diagnostics. This is why we have fully automated and detailed module identification incorporated

Reading and clearing of diagnostic trouble codes (DTCs) with complete information as per the available data in the electronic control modules.

Actual values are also a part of the standard diagnostics, they allow you to monitor various parameters from the vehicle's sensors hence aiding a more accurate diagnostic procedure. Live values from multiple electronic control modules simultaneously.

Actuator testing is another helpful feature included here due to the fact that the vehicle's actuators can be tested separately in order to determine the sourse of an issue. Actuator tests for all possible actuators installed in the vehicles.

Graphic Details

- Renew of electronic control modules including Airbag modules and clearing of crash data.

- Configuration and testing from the production line - here the Abrites Diagnostic Software also provides the ability to perform these tests

The true power of the Abrites Diagnostics for Renault, however, is demonstrated when the software reaches the advanced levels of diagnostics. Where standard diagnostic software
is not enough the Abrites Diagnostics for Renault demonstrates its special functions.Some of the main features of the special functions include:

  • PIN code reading and key learning functionality - This functionality was created with the automotive locksmith in mind, It stands out ahead of its competition with its ease of usage and speed making even the most time costly task achievable.
  • Reading and Mileage calibration with the added option to disable the synchronization between the cluster and the ABS module - Ideal for replacing components containing the vehicle mileage. Once you replace the faulty mileage containing module you can set the value to the car's actual mileage with no more than a few clicks. Incrementing and decrementing is availabe in this option.
  • Car ID replacement for various modules. Again when replacing a faulty module with a used one of the same car you will need to adapt the module ID to the car in order to ensure that the vehicle is roadworthy and this is where this function of the Abrites Diagnostics for Renault will be very useful.
  • Airbag memory manager - Allows the user to manage the stored data in the airbag and some of the Airbag modules, available in the Renault vehicles. Ideal for an automotive shop, specializing in accident damage repairs.


Special functions:

This function allows the user to calibrate the mileage in all relevant modules. Please note that regarding the vehicle models that use ABS synchronization there is the added option to disable the sync. This special function also provides the option to read and write the EEPROM and flash so that in case of any issues during calibration or others you can repair the vehicle.

Supported models:

This function allows the user to read the PIN code directly from the device and proceed with key learning immediately.
The function applies to key-cards, as well as metal cut keys.

Renault Captur 2013+ Dacia Dokker 2012+ Opel Movano Ph2 2002-2006 Nissan Platina 2002-2008 Renault-Samsung QM3 2013+
Renault Clio II Ph2/3 X65 2002-2006 Dacia Duster Opel Movano Ph3 2007+ Nissan Primestar Ph2 2002-2006 Renault-Samsung QM5
Renault Clio III 2005+ Dacia Lodgy  Opel Movano B 2010+ Nissan Primestar Ph3 2007+ Renault-Samsung SM3 2006+
Renault Clio III with key card Dacia Logan X90 Opel Vivaro 2002-2006   Renault-Samsung SM3 2009-2011
Renault Clio IV 2012+ Dacia Logan Ph2 X90 2008+ Opel Vivaro Ph2 2007+   Renault-Samsung SM3 2011+
Renault Clio Campus 2006+ Dacia Logan II Opel Vivaro 2014+   Renault-Samsung SM5 2009-2011
Renault Clio Classic Dacia Sandero B90 FIAT Talento 2017+   Renault-Samsung SM5 2011+
Renault Clio Sedan Dacia Sandero II
Renault Clio Symbol Dacia Solenza 2003-2005
Renault Clio Thalia
Renault Espace IV X81 2003-2006
Renault Espace IV Ph2 X81 2006+
Renault Fluence
Renault Grand Modus 2008+
Renault Kangoo MUX Ph2 X76 2002-2007
Renault Kangoo X61 2008+
Renault Koleos 2007-2015
Renault Laguna Coupe 2011+
Renault Laguna II X56 2000-2005
Renault Laguna II ph2 X56 2005+
Renault Laguna III X91
Renault Latitude
Renault Master Ph2 X70 2002-2006
Renault Master Ph3 X70 2007+
Renault Master III X62 2010+
Renault Megane II X84 2003-2006
Renault Megane II Ph2 X84 2006+
Renault Megane III X95 2008-2015
Renault Modus
Renault Safrane
Renault Scenic II X64 2003-2006
Renault Scenic II Ph2 X64 2006+
Renault Scenic III X95
Renault Symbol III 2012+
Renault Traffic II X83 2002-2006
Renault Traffic II Ph2 X83 2007-2014
Renault Traffic III X82 2014+
Renault Twingo Ph2 X06 2002-2007
Renault Twingo II X44 2007+
Renault Twingo III 2014+
Renault Valsatis X73 2002+
Renault Valsatis Ph2 X73 2006+
Renault Wind

* Programmer is also needed - ZN002 - PROTAG programmer

* Reading and updating the EEPROM of the following ECUs:
- EDC15C3
- EDC15C13
- EDC17
- SID301
- SIM32
- SAFIR/SAFIR2/SAFIR200 (reading only)
- IAW 6R.20
- IAW 6R.30 (reading only)

* Reading and updating the FLASH of the following ECUs:
- EDC15C3
- EDC15C13
- EDC17
- SID301
- SIM32

* Clearing IMMO code data for the following ECUs:
- EDC15C3
- EDC15C13
- SID301
- SIM32
- IAW 6R.30
